部分電機軸承預緊波形彈簧波形墊圈參數如下：
零件號 軸承外徑 配合軸徑 負荷 工作高度 自由高度 波數 ?厚度 寬度 ??彈性系數
|
180035
|
9
|
6.86
|
25.8
|
1
|
1.5
|
3
|
0.2
|
0.81
|
52
|
|
180039
|
10
|
7.49
|
27.6
|
1
|
1.57
|
3
|
0.2
|
1.02
|
48
|
|
180043
|
11
|
8.46
|
29.4
|
1
|
1.83
|
3
|
0.2
|
1.02
|
35
|
|
180047
|
12
|
9.17
|
33.4
|
1
|
1.57
|
3
|
0.25
|
1.17
|
59
|
|
180051
|
13
|
9.53
|
37.8
|
1
|
1.57
|
3
|
0.25
|
1.47
|
66
|
|
180063
|
16
|
11.28
|
44.5
|
1.57
|
2.29
|
3
|
0.25
|
1.98
|
65
|
|
180075
|
19
|
14.28
|
53.4
|
1.57
|
3.05
|
3
|
0.25
|
1.98
|
35
|
|
180087
|
22
|
16.46
|
62.3
|
1.57
|
2.79
|
3
|
0.3
|
2.39
|
48
|
|
180095
|
24
|
18.46
|
66.7
|
1.57
|
3.56
|
3
|
0.3
|
2.39
|
35
|
|
180102
|
26
|
18.22
|
71.2
|
1.98
|
2.54
|
3
|
0.41
|
3.38
|
111
|
|
180110
|
28
|
20.22
|
75.6
|
1.98
|
2.79
|
3
|
0.41
|
3.38
|
85
|
|
180118
|
30
|
22.22
|
84.5
|
1.98
|
3.3
|
3
|
0.41
|
3.38
|
66
|
|
180126
|
32
|
24.22
|
89
|
1.98
|
3.81
|
3
|
0.41
|
3.38
|
52
|
|
180138
|
35
|
27.22
|
97.9
|
1.98
|
4.57
|
3
|
0.41
|
3.38
|
38
|
|
180146
|
37
|
28.72
|
102.3
|
1.98
|
3.81
|
3
|
0.46
|
3.63
|
58
|
|
180158
|
40
|
31.72
|
111.2
|
1.98
|
5.08
|
3
|
0.46
|
3.63
|
37
|
|
180165
|
42
|
33.72
|
115.7
|
1.98
|
3.05
|
4
|
0.46
|
3.63
|
99
|
|
180185
|
47
|
38.72
|
129
|
1.98
|
3.81
|
4
|
0.46
|
3.63
|
68
|
|
180205
|
52
|
43.11
|
142.4
|
2.36
|
3.56
|
4
|
0.61
|
3.81
|
121
|
|
180217
|
55
|
46.11
|
151.3
|
2.36
|
3.81
|
4
|
0.61
|
3.81
|
100
|
|
180244
|
62
|
51.69
|
169.1
|
2.36
|
4.32
|
4
|
0.61
|
4.52
|
85
|
|
180268
|
68
|
57.17
|
186.9
|
2.77
|
4.32
|
4
|
0.76
|
4.78
|
131
|
|
180276
|
70
|
59.17
|
191.3
|
2.77
|
4.32
|
4
|
0.76
|
4.78
|
119
|
|
180284
|
72
|
61.17
|
195.8
|
2.77
|
4.57
|
4
|
0.76
|
4.78
|
108
|
|
180295
|
75
|
64.17
|
204.7
|
2.77
|
5.08
|
4
|
0.76
|
4.78
|
94
|
|
180315
|
80
|
68.66
|
218
|
2.77
|
5.59
|
4
|
0.76
|
4.78
|
76
|
|
180335
|
85
|
71.38
|
231.4
|
2.77
|
5.59
|
4
|
0.76
|
5.92
|
83
|
|
180354
|
90
|
76.38
|
249.2
|
2.77
|
6.35
|
4
|
0.76
|
5.92
|
68
|
|
180374
|
95
|
81.38
|
262.5
|
2.77
|
7.37
|
4
|
0.76
|
5.92
|
57
|
|
180394
|
100
|
86.38
|
275.9
|
2.77
|
4.57
|
5
|
0.76
|
5.92
|
157
|
|
180413
|
105
|
91.38
|
289.2
|
2.77
|
5.08
|
5
|
0.76
|
5.92
|
134
|
|
180433
|
110
|
96.38
|
302.6
|
2.77
|
5.33
|
5
|
0.76
|
5.92
|
115
|
|
180453
|
115
|
101.38
|
315.9
|
3.18
|
6.35
|
5
|
0.76
|
5.92
|
99
|
|
180472
|
120
|
106.38
|
329.3
|
3.18
|
7.11
|
5
|
0.76
|
5.92
|
86
|
|
180492
|
125
|
111.38
|
342.6
|
3.18
|
7.62
|
5
|
0.76
|
5.92
|
76
|
|
180512
|
130
|
116.38
|
356
|
3.18
|
8.64
|
5
|
0.76
|
5.92
|
67
|
|
180532
|
135
|
121.38
|
369.3
|
3.18
|
9.4
|
5
|
0.76
|
5.92
|
59
|
|
180551
|
140
|
126.38
|
382.7
|
3.18
|
6.86
|
6
|
0.76
|
5.92
|
108
|
|
180571
|
145
|
131.38
|
396
|
3.18
|
7.37
|
6
|
0.76
|
5.92
|
97
|
|
180591
|
150
|
136.38
|
404.9
|
3.18
|
7.87
|
6
|
0.76
|
5.92
|
87
|
|
180630
|
160
|
146.38
|
440.5
|
3.18
|
9.4
|
6
|
0.76
|
5.92
|
71
|
|
180650
|
165
|
151.38
|
453.9
|
3.18
|
10.41
|
6
|
0.76
|
5.92
|
64
|
|
180669
|
170
|
156.38
|
467.2
|
3.18
|
11.18
|
6
|
0.76
|
5.92
|
58
|
|
180689
|
175
|
154.16
|
480.6
|
3.96
|
8.13
|
6
|
0.81
|
9.53
|
116
|
材質可選：碳鋼、304不銹鋼、316不銹鋼、Inconel X-750等多種材質。
表面處理：鈍化、煮黑、磷化、鍍鎘、震動去毛刺等多種方式。
另可專業定制各規格、各材質、各種表面處理的波形彈簧和墊圈。專業技術人員設計、無模具費、生產周期不到一個月。
